Xuanan Lighting Launches Unique Flower‑Shaped Eaves Light with UCS7604 RGBW Chip
Shenzhen, China – June 2026
Since around 2020, the North American market — particularly the United States and Canada — has seen a significant surge in demand for eaves lights (also known as permanent outdoor LED accent lights). This trend has now continued for over five years.
However, most of the products commonly available are variations of the same design: a 30mm lens‑type light, available in DC12V, DC24V, or DC48V, often with UL or ETL certification. While functional, these products have become ubiquitous — "overused" in the eyes of many homeowners and contractors.
Through years of experience in the lighting export business and a deep understanding of the North American market, we have observed a clear pattern:
Many customers want something different. They want unique designs.
But the high cost of mold development has held them back.
Today, we are changing that.
Introducing the Flower‑Shaped Eaves Light
Xuanan Lighting is proud to introduce our new flower‑shaped eaves light — a distinctive alternative to the standard lens‑type products flooding the market.
Feature | Specification |
|---|---|
Model | XXA-F-ICRGBW |
Shape | Flower (unique design, not the standard 30mm lens type) |
LED type | SMD5054 RGBW (high brightness, wide beam angle) |
IC chip | UCS7604 RGBW (advanced bad‑point continuation series) |
Input voltage | DC24V |
Power | 1.5W per piece |
Control | Sound control / Remote control / Phone App |
Grayscale | 65,536 levels per channel (16‑bit) |
Port refresh frequency | 16KHz |
IP rating | IP67 (waterproof for outdoor use) |
Material | Flame‑retardant, weather‑resistant transparent PVC |
Chip brand | Sanan (original, excellent color consistency) |
Lifespan | ≥50,000 hours |
Beam angle | ≥95° |
Constant current accuracy | ±5%, 0‑60mA adjustable per channel |
Why UCS7604? Advanced Chip Technology Behind the Light
Most eaves lights on the market use conventional RGBW chips such as UCS2904. Our flower‑shaped eaves light uses the UCS7604 — a member of the intelligent bad‑point continuous transmission series with several industry‑leading features.
Why this matters: The UCS7604 delivers higher reliability (bad‑point continuity), smoother color performance (65,536 vs 256 grayscale levels), and greater design flexibility (independent RGBW current adjustment) compared to conventional eaves light chips.
Built for North American Outdoor Conditions
Eaves lights are installed outdoors and must withstand sun, rain, snow, and temperature extremes. Our flower‑shaped eaves light is engineered for durability:
IP67 waterproof — fully protected against dust and temporary immersion
UV‑resistant casing — prevents yellowing and cracking from sunlight exposure
Cold‑resistant wire — suitable for freezing winter temperatures
Flame‑retardant material — adds an extra layer of safety
Ultrasonic sealing — prevents insect ingress, moisture, and dust
Whether installed on a residential roofline, a commercial building facade, or a KTV entertainment venue, this product is built to last.
No Mold Cost Worry – Unique Design Now Accessible
The biggest barrier to unique designs has always been mold development costs. Many customers hesitate to invest in custom‑shaped products because of the upfront tooling expense.
We have addressed this concern.
Our flower‑shaped eaves light is available as a standard product — meaning you can offer a unique design to your customers without paying for custom mold development.
Benefit: Differentiate your offering from competitors using the same old lens‑type lights, at no additional tooling cost.
Applications
The flower‑shaped eaves light is versatile and suitable for a wide range of applications:
Control Options: Sound, Remote, and App
Unlike many basic eaves lights that offer limited control, our flower‑shaped light supports three control methods:
With 65,536‑level grayscale and digital full‑color capability, you can achieve ultra‑smooth color transitions, dynamic effects, and precise color matching.
Summary: Why Choose Our Flower‑Shaped Eaves Light?
Advantage | What It Means for You |
|---|---|
Unique flower shape | Stand out from standard 30mm lens‑type lights |
UCS7604 RGBW chip | Bad‑point continuity, 65,536 grayscale levels, 16KHz refresh, independent RGBW current control |
No mold development cost | Unique design without expensive tooling |
IP67 waterproof | Reliable for long‑term outdoor use |
Multiple control options | Sound, remote, or App — flexible for any project |
Sanan original chips | Consistent color, high brightness, long lifespan |
Proven for North America | UV‑resistant, cold‑resistant, flame‑retardant |
Ready to Differentiate Your Eaves Light Offering?
If you are tired of offering the same "overused" lens‑type eaves lights as everyone else, it is time to consider something different.
👉 Contact Us to request samples, specifications, or a quote for our flower‑shaped eaves light with UCS7604 RGBW chip.
